Cylinder Head Bolts for Ford Ranger 2.5 3.0 TDCi TDdi for Mazda BT50 Twin Cam

In stock
Be the first to review this product
£21.99
SKU : FDAF3991
  • Secure Payments
  • Worldwide Delivery Options
Categories:
Cylinder Head Bolts ​ ​ For following Ford Engines- FORD - WEAT FORD - WLC For following Mazda Engines- MAZDA - WLAT (16 V) MAZDA - WEAT ​ ​ Bolt Dimensions - 10pc Thread Size- M12 Thread Length - 48mm Length Under Cap -113mm Total Length - 126.5 mm Thread Pitch - 1.5 Thread Diameter - 12mm Bolt Head Diameter - 15.5mm Bolt Head/ Nut design - Male Torx ​ ​ ​ Bolt Dimensions - 4pc Thread Size- M10 Thread Length - 48 mm Length Under Cap -100mm Total Length - 113 mm Thread Pitch - 1.25mm Thread Diameter - 10 mm Bolt Head Diameter - 15.5 mm Bolt Head/ Nut design - Male Torx ​ ​ ​ Bolt Dimensions - 4pc Thread Size- M10 Thread Length - 55 mm Length Under Cap -149.5 mm Total Length - 160 mm Thread Pitch - 1.25 Thread Diameter - 10mm Bolt Head Diameter - 15.5mm Bolt Head/ Nut design - Male Torx ​ ​ OEM Part Number Reference- ​ 81042200 - WE0110137A - RF0110135A - WL0110135 Additional Discounts Offered For In Store Collection. Please Ensure To Thoroughly Check All Images, Part Numbers And Models Before Purchasing. ​ ​

Cylinder Head Bolts


For following Ford Engines-
FORD - WEAT
FORD - WLC
For following Mazda Engines-
MAZDA - WLAT (16 V)
MAZDA - WEAT


Bolt Dimensions - 10pc

Thread Size- M12
Thread Length - 48mm
Length Under Cap -113mm
Total Length - 126.5 mm
Thread Pitch - 1.5
Thread Diameter - 12mm
Bolt Head Diameter - 15.5mm
Bolt Head/ Nut design - Male Torx



Bolt Dimensions - 4pc

Thread Size- M10
Thread Length - 48 mm
Length Under Cap -100mm
Total Length - 113 mm
Thread Pitch - 1.25mm
Thread Diameter - 10 mm
Bolt Head Diameter - 15.5 mm
Bolt Head/ Nut design - Male Torx



Bolt Dimensions - 4pc

Thread Size- M10
Thread Length - 55 mm
Length Under Cap -149.5 mm
Total Length - 160 mm
Thread Pitch - 1.25
Thread Diameter - 10mm
Bolt Head Diameter - 15.5mm
Bolt Head/ Nut design - Male Torx



OEM Part Number Reference-

81042200 - WE0110137A - RF0110135A - WL0110135



Additional Discounts Offered For In Store Collection.

Please Ensure To Thoroughly Check All Images, Part Numbers And Models Before Purchasing.
